Ligra DS distributes the new Canon CR-X300

Canon CR-X300

New CR-X300 Portable Outdoor PTZ

CR-X300 is part of Canon's range of 4K PTZ cameras suitable for outdoor use.
IP connectivity and streaming protocols, and a compact, weatherproof IP65-rated body make this PTZ perfect for both broadcast and all-weather monitoring and security applications.

Main features

  • Impressive images and Full HD
  • Versatile, high-quality 20x optical zoom
  • Advanced streaming and output options
  • Hybrid AF for precise focusing
  • Smooth and precise controls
  • Effective even under difficult environmental conditions
  • Customised image settings
  • Robust and durable body
  • Optimised for outdoor use with IP65 protection frame
  • Outputs 6G-SDI/HDMI/LAN (PoE++)

Close to reality with extreme sharpness


Impressive 4K Full HD images

A 1/2.3″ 4K/UHD CMOS sensor with DIGIC DV6 image processor captures detailed footage up to 4K 30P at 4:2:2/10 bit. Video can be processed in superior Full HD quality thanks to 4K oversampling.



Robust and durable body

IP65 protection against water, dust and salt to guarantee performance from -15° to +40°C in humidity of the 90%. The fully sealed housing also features an integrated cleaning system for a clear view.



Hybrid AF
for precise focusing

The CR-X300 combines high-precision contrast AF with high-speed phase-detection AF, ensuring accurate focusing of the subject, even in low-light conditions.


Advanced streaming and output options

The CR-X300 is extremely flexible with 6G SDI and HDMI outputs, PoE++ and network connectivity supporting protocols such as Canon XC, RTP/RTSP, RTMP/RTMPS and NDI|HX video transmission, as well as communication, streamin and control protocols.


Versatile 20x optical zoom
and high quality

The CR-X300 features a 20x optical zoom lens with a focal length of 29.3-601mm (35mm equivalent) in UHD as well as the option of a 20x digital zoom. The CR-X300 also features Canon's 4-axis image stabilisation system for increased stability during shooting.



Smooth and precise controls

The CR-X300 is able to perform simultaneous high-precision panning, tilting and zooming movements at a speed of 0.3 degrees/sec, even at default settings, and is compatible with Canon's RC-IP100 controller, the Remote Camera Control application and certain third-party options.
